NON FLAMMABLE FABRIC
MARKO AT180
Antistatic
Antistatic
The MARKO AT180 flame-retardant fabric provides comfortable protection against fire and heat, combining lightness, durability, and comfort for PPE garments.
Weight
220 g/m² ± 5%
Weave
Tafetán
Width
152 cm
COLORS
Description
Marina Textil’s MARKO AT180 technical fabric is a permanently flame-retardant material designed to provide effective protection against fire and heat in industrial environments. With a weight of 220 g/m² and a taffeta weave, it stands out for its lightness, breathability, and comfort, making it ideal for garments intended for prolonged use in personal protective equipment (PPE). This multi-standard fabric offers protection against flame spread, convective, radiant, and contact heat, as well as resistance to electric arcs and antistatic properties, complying with international standards such as EN ISO 11612, EN 1149, and IEC 61482-2. Thanks to its balance between protection and comfort, MARKO AT180 is particularly well-suited for sectors such as industry, utilities, energy, and maintenance. Additionally, it can incorporate various technical finishes into its specifications, such as HV (high visibility) or FC (acid-resistant), allowing the fabric to be adapted to specific needs and enhancing its performance in hazardous environments.catalog.tab_tech
| Characteristics | Standard | Result |
|---|---|---|
| Heat Resistance (180ºC) | ISO 17493 | PASS |
| Heat Resistance (260ºC) | ISO 17493 | PASS |
| Limited Flame Spread (H) | UNE-EN ISO 15025 (A) | A1 |
| Limited Flame Spread (V) | UNE-EN ISO 15025 (B) | A2 |
| Convective Heat (s) | UNE-EN ISO 9151 | B1 |
| Radiant Heat (s) | UNE-EN ISO 6942 | C1 |
| Contact Heat | UNE-EN ISO 12127-1 | F1 |
| Electric Arc (Elim) (cal/cm2) | EN 61482-1-1 | 6,8 |
| Electric Arc (Ebt) (cal/cm2) | EN 61482-1-1 | 7,4 |
| Electric Arc (Ebt) (cal/cm2) | ASTM F1959 | 5,5 |
| Electric Arc (HAF) (%) | ASTM F1959 | 74,2 |
| Electric Arc (Box test) | EN 61482-1-2 | APC 1 |
| Antistatic | UNE-EN 1149-3 | PASS |
| High visibility | UNE-EN ISO 20471 | MARKO AT180HV |
| Antacid | UNE-EN 13034 | MARKO AT180FC |
| Water vapour resistance - Ret (m2·Pa/W) | UNE-EN ISO 11092 | 3,2074 |
| Thermal Resistance - Rct (m2·K/W) | UNE-EN ISO 11092 | 0,0206 |
| Tensile Strength Warp (N) | UNE-EN ISO 13934-1 | 810 ±10% |
| Tensile Strength Weft (N) | UNE-EN ISO 13934-1 | 415 ±10% |
| Tear Resistance Warp (N) | UNE-EN ISO 13937-2 | 25 (-5N) |
| Tear Resistance Weft (N) | UNE-EN ISO 13937-2 | 30 (-5N) |
| Dimensional Change Warp (%) | UNE-EN ISO 5077 | <3% |
| Dimensional Change Weft (%) | UNE-EN ISO 5077 | <3% |
REV.
1
Certifications
EN ISO 11612
IEC 61482
EN 1149
EN ISO 20471
EN 13034
ASTM F1959
EN 1149-5
Risks
High visibility
Molten metal splashes
Electric arc
Antistatic
Antacid
Heat and flames
Washing Info
