MARKOL SSH500
Flame-retardant laminated technical fabric that provides protection against heat and flame, combining antistatic properties and resistance to chemical agents with a high level of durability.
Weight
14.6 oz (sq yd) - 495 g/m² ± 5%
Weave
Tejido laminado
Width
1.64 yd - 150 cm
COLORS
Description
MARKOL SSH500 is a flame-retardant laminated technical fabric developed to provide effective protection against fire and heat in demanding industrial environments. Its structure offers high mechanical resistance and durability, making it suitable for intensive applications. This fabric protects against heat and flame, electric arc, small splashes of molten metal, and electrostatic risks, ensuring a high level of safety in critical working conditions. It features antistatic properties, which help dissipate electrical charges, as well as resistance to chemical agents and splashes, making it suitable for aggressive environments where additional protection is required. In addition, its laminated structure enhances overall user protection, while maintaining dimensional stability and long-term performance. With an approximate weight of 495 g/m², it provides a robust and reliable solution, ensuring an optimal balance between protection and performance.catalog.tab_tech
| Characteristics | Standard | Result |
|---|---|---|
| Limited Flame Spread (H) | UNE-EN ISO 15025 (A) | A1 |
| Convective Heat (s) | UNE-EN ISO 9151 | B1 |
| Radiant Heat (s) | UNE-EN ISO 6942 | C1 |
| Contact Heat | UNE-EN ISO 12127-1 | F1 |
| Limited Flame Spread (American Vertical) | ASTM D 6413 | PASS |
| HTP with spacer (cal/cm2) | ASTM F2700-08 | >= 6 |
| HTP without spacer (cal/cm2) | ASTM F2700-08 | >= 3 |
| Manikin test | ASTM F 1930 | < 50 % |
| Electric Arc (ATPV) (cal/cm2) | ASTM F1959 | 43 |
| Antistatic | UNE-EN 1149-3 | PASS |
| High visibility | UNE-EN ISO 20471 | MARKO SSH500HV |
| Antacid | UNE-EN 13034 | PASS |
| Dimensional Change Warp (%) | UNE-EN ISO 5077 | < 5% |
| Dimensional Change Weft (%) | UNE-EN ISO 5077 | < 5% |
REV.
3
Certifications
EN ISO 11612
IEC 61482
EN 1149
EN ISO 20471
EN 13034
NFPA 2112
ASTM F1959
EN 1149-5
Risks
High visibility
Molten metal splashes
Contact heat
Electric arc
Antistatic
Antacid
Heat and flames
