PLUSMARK AT295HV

Name: PLUSMARK AT295HV
Brand: Marina Textil
SKU: PLUSMARK AT295HV

Comfortable protection against fire and heat.

Weight 315 g/m² ± 5%

Weave Sarga 3/1

Width 153 cm

Characteristics	Standard	Result
Heat Resistance (180ºC)	ISO 17493	PASS
Limited Flame Spread (H)	UNE-EN ISO 15025 (A)	A1
Convective Heat (s)	UNE-EN ISO 9151	B1
Radiant Heat (s)	UNE-EN ISO 6942	C1
Molten Metal Splashes (Iron)	UNE-EN ISO 9185	E2
Contact Heat	UNE-EN ISO 12127-1	F1
Electric Arc (Elim) (cal/cm2)	EN 61482-1-1	12
Electric Arc (ATPV) (cal/cm2)	EN 61482-1-1	15
Electric Arc (Ebt) (cal/cm2)	ASTM F1959	13
Electric Arc (HAF) (%)	ASTM F1959	84,2
Electric Arc (Box test)	EN 61482-1-2	APC 1
Welding and allied processes	UNE-EN ISO 11611	CLASS 1
Antistatic	UNE-EN 1149-3	PASS
High visibility	UNE-EN ISO 20471	PASS
Antacid	UNE-EN 13034	PLUSMARK AT295FC
Water vapour resistance - Ret (m2·Pa/W)	UNE-EN ISO 11092	3,82
Tensile Strength Warp (N)	UNE-EN ISO 13934-1	1.320 ±10%
Tensile Strength Weft (N)	UNE-EN ISO 13934-1	1.285 ±10%
Tear Resistance Warp (N)	UNE-EN ISO 13937-2	50 (-5N)
Tear Resistance Weft (N)	UNE-EN ISO 13937-2	50 (-5N)
Dimensional Change Warp (%)	UNE-EN ISO 5077	<3%
Dimensional Change Weft (%)	UNE-EN ISO 5077	<3%
